HTG High Efficient Solid Liquid Separation Equipment,Ceramic Filter
The company has started developing and manufacturing ceramic filters since the 1990s. HTG full-automatic ceramic filter is new, efficient, energy-saving and environment-friendly high-tech dewatering equipment that integrates micro-porous ceramics, electromechanical and ultrasonic technologies and automatic control. And it is rated as National Key New Product. Our company has many national invention patents for it. It is the unit in charge of taking the lead to draft the national industry standard on ceramic filter.
Dedicated in R&D and production of micro-porous ceramics and structural ceramics for 60 years, the company has the international advanced and domestic leading R&D equipment and solid R&D strength. The core technology of ceramic filters---microporous ceramic filter plates, shows our professional and technical advantages in this field.
Our microporous ceramic products have been widely used in environmental protection industries such as exhaust gas emission, water treatment and dust removal in many countries and regions. We insist on innovation and progress to provide more valuable products and services to users around the world.
Model Parameter |
HTG01/1 | HTG06/3 | HTG09/3 | HTG12/3 | HTG15/3 | HTG18/3 | HTG21/3 | HTG24/3 | HTG30/3 |
Filtration area | 1 | 6 | 9 | 12 | 15 | 18 | 21 | 24 | 30 |
Installed power | 6 | 8 | 10 | 11 | 14 | 15 | 15 | 15 | 18 |
Weight(t) | 2.2 | 5.6 | 7.9 | 8.5 | 9.2 | 9.9 | 10.2 | 11.2 | 12.8 |
Length (mm) | 1910 | 3062 | 4170 | 4360 | 4770 | 4780 | 5375 | 5453 | 6318 |
Width(mm) | 1900 | 3025 | 2935 | 3200 | 3200 | 3200 | 3200 | 3200 | 3400 |
Height (mm) | 1780 | 2750 | 2750 | 2750 | 2750 | 2750 | 2750 | 2750 | 2750 |
Model Parameter |
HTG45/3 |
HTG51 / 3.75 |
HTG45 / 3.75 | HTG60/4 | HTG80/4 | HTG15/5 | HTG20/5 | HTG25/5 | HTG30/5 |
Filtration area | 45 | 51 | 45 | 60 | 80 | 15 | 20 | 25 | 30 |
Installed power | 22 | 22 | 22 | 30 | 40 | 17 | 17 | 18 | 20 |
Weight(t) | 15.6 | 13.1 | 12 | 18.5 | 24 | 7 | 7.2 | 7.9 | 9.5 |
Length (mm) | 7998 | 6300 | 6100 | 8054 | 9562 | 3930 | 4470 | 4690 | 4810 |
Width(mm) | 3410 | 3020 | 3020 | 3150 | 3510 | 3410 | 3510 | 3510 | 3510 |
Height (mm) | 2750 | 2720 | 2720 | 3270 | 3233 | 2980 | 2980 | 2980 | 3035 |
Model Parameter |
HTG45 /5 |
HTG50 /5 |
HTG60 /5 |
HTG80 /5 |
HTG100 /5 |
HTG120 /6 |
HTG144 /12 |
HTG180 /12 |
HTG204 /12 |
HTG240 /12 |
Filtration area | 45 | 50 | 60 | 80 | 100 | 120 | 144 | 180 | 204 | 240 |
Installed power | 22 | 22 | 29 | 39 | 43 | 57 | 67 | 114 | 116.8 | 121 |
Weight(t) | 11.3 | 12.5 | 14 | 18.5 | 23 | 25 | 28.5 | 39 | 42 | 45 |
Length (mm) | 5470 | 5690 | 6130 | 7253 | 8094 | 9437 | 7260 | 9670 | 10470 | 11670 |
Width(mm) | 3510 | 3510 | 3510 | 3510 | 3510 | 3565 | 5330 | 5330 | 5330 | 5330 |
Height (mm) | 3035 | 3035 | 3035 | 3035 | 3035 | 3295 | 4786 | 4786 | 4786 |
4786 |
Customizable
